3 Phase Intelligent PDU Set LCD IPDU Header Three-Phase Lower Detection Plate Magnetically Held Relay Meter

JSY-IPDU002

Description:

Professional-grade network remote monitoring and management power distribution system is the latest scientific research achievement in the field of power distribution technology after years of dedicated research. This product is based on the development trend of the world’s future power distribution monitoring and management technology, combined with the technical requirements of the modern data center application environment, using the latest core technology with completely independent intellectual property rights, integrating network communication, power distribution, power metering and other technologies, and is the latest network remote monitoring and management power distributor carefully designed.

Contact

Product Detail

OEM/ODM SERVICES

CUSTOMER SERVICES

Product Tags

IPDU Product Components

Module No.: JSY-MK-352

Intelligent IPDU Header

[ Adapt to 1 Phase and 3 Phase ]

①TFT color screen (2.0 inches)
②1-channel Ethernet port
③1-channel RS485 IN OUT cascade port
④1-channel USB software upgrade port
⑤6 RJ11 interfaces 【2-channel temperature and humidity, 4-channel switch inputs(supports Water immersion, door access control, smoke detection), 2-channel switch outputs, 1-channel 485(Reserved function)】

Module No.: JSY-MK-352AFE

Three phase power module

①Voltage: 3*220V / 380V
②Current: 3*32A
③Frequency: 50Hz or 60Hz
④Accuracy: ±1%

Module No.: JSY1084

4-channel metering control auxiliary module (magnetically held relay)

①220V AC input
②4-channel 50A current detection
③4-channel 50A magnetic retention relay control
④4-channel indicator output
⑤Accuracy: ±1%

IPDU Product Introduce

Single-phase and three-phase smart PDU meters are based on the innovative SUM (sustainable, scalable and maintainable) design concept technology. As a key component of the metering cabinet power distribution unit (PDU), after being installed into the main body of the PDU, it can Provides active metering capabilities for energy optimization and circuit protection. User-set alarm thresholds can effectively reduce risks by warning of potential circuit overloads through real-time local and remote alarms. Metered rack PDUs provide power usage data to support data center managers in making informed decisions about load balancing and proper IT sizing, thereby significantly reducing total cost of ownership. Users can configure metered cabinet PDU via Ethernet access or RS485. This series of products can be widely used in data center rooms such as IDC, banks, securities, governments, and enterprises.

IPDU Product Network Functions Interface Show

- Support WEB method to log in to the management page, and use user name + password to realize the login function.
- The interface includes the main interface, output information interface, sensor information interface, network setting interface, device information interface, user management interface and factory reset interface.
